| Heading | Value |
| Product Type | Single Tube Indoor/Outdoor Fiber Optic Cable |
| Fiber Type | Singlemode / Multimode |
| Fiber Count | 6 / 12 Fibers |
| Loose Tube Material | PBT with Thixotropic Jelly Compound |
| Fibers per Tube | 6 / 12 |
| Loose Tube Diameter | Approx. 2.5 mm |
| Water Blocking Tape | NWF, 0.3 mm |
| Strength Member | Aramid Yarn / E-Glass Yarn |
| Cable Sheath Material | HDPE with LSZH, 1.6 ± 0.2 mm |
| Rodent Protection | Rodent Repellent (LS2) |
| Core Diameter | Singlemode 9 µm / Multimode 50 µm |
| Cladding Diameter | 125 µm |
| Coating Diameter | 250 µm |
| Overall Cable Diameter | Approx. 4.5 mm |
| Cable Weight | Approx. 9.6 ± 1.0 kg/km |
| Short-Term Tensile Strength | 2700 N |
| Long-Term Tensile Strength | 600 N |
| Short-Term Crush Resistance | 2000 N/100 mm |
| Long-Term Crush Resistance | 1000 N/100 mm |
| Minimum Bending Radius – Dynamic | 15 × Cable Diameter |
| Minimum Bending Radius – Static | 10 × Cable Diameter |
| Storage Temperature | -40°C to +75°C |
| Installation Temperature | -40°C to +80°C |
| Rip Cord Material | Polyester Cord |
