F-Z9-01-SX

Name: F-Z9-01-SX
Brand: FOCOMM
SKU: FFB-003
Availability: OutOfStock

SKU: FFB-003

Fiber Optic Zipcord Indoor Cable, Simplex, 9/125 SM, 1Core

SI Price (excl. VAT)

Call

per pcs · MOQ: 1

Stock

Actual: 0 units

Planning: 0 units

Shipping Conditions

Warranty

30 Year Manufacturer Warranty

Product Highlights

Heading	Value
Product Type	Indoor Fiber Optic Cable
Cable Type	Simplex / Duplex
Fiber Type	Singlemode / Multimode
Optical Fiber Count	2 Fibers
Tight Buffer Material	LSZH
Tight Buffer Diameter	0.85 ± 0.05 mm
Strength Member	Aramid Fiber
Cable Dimension	2.0 ± 0.2 × 4.1 ± 0.2 mm
Outer Jacket Material	LSZH
Outer Jacket Color	Yellow
Short-Term Tensile Load	100 N
Long-Term Tensile Load	50 N
Short-Term Crush Resistance	500 N/100 mm
Long-Term Crush Resistance	250 N/100 mm
Cable Attenuation	≤ 0.4 dB/km at 1310 nm / ≤ 0.3 dB/km at 1550 nm
Cable Weight	Approx. 7.6 kg/km
Minimum Bending Radius – Static	10 × Cable Diameter
Minimum Bending Radius – Dynamic	20 × Cable Diameter
Operating Temperature	-40°C to +70°C
Installation Temperature	-40°C to +70°C
Storage / Transportation Temperature	-40°C to +70°C
