| Mechanics | - |
| Dimensions | 360mm(L)*193mm(W)*44mm(H) |
| Weight | 1.70Kg |
| Hardware | - |
| Uplink Port | - |
| Ethernet Ports | 2*10/100/1000M auto-negotiation Ethernet ports |
| Gigabit Uplink Port | 1*10 Gigabit uplink port |
| PON Port | - |
| Quantity | 2 |
| Physical Interface | SFP slot |
| Interface Type | GPON: ITU-T G.984.2 Class B+/Class C+ |
| Max Splitting Ratio | GPON: 1:128 |
| Management Port | 1 CONSOLE local management port |
| PON Port Attribute | - |
| Transmission Distance | 20KM |
| Port Rate | GPON: Downstream: 2.5Gbps / Upstream: 1.25Gbps |
| Wavelength | Forwarding: 1490nm / Receiving: 1310nm |
| Fiber Type | 9/125μm SMF (Single Mode Fiber) |
| Light Transmission Power | Class B+: +1.5 ~ +5dBm / Class C+: +3 ~ +7dBm |
| Receiving Sensitivity | Class B+: -28dBm / Class C+: -30dBm |
| Saturation Power | Class B+: -8dBm / Class C+: -12dBm |
| Backplane Bandwidth | 31.5G |
| Power Supply | - |
| AC | 100V ~ 240V, 47~63Hz |
| DC | External adapter mode 12V/2.5A |
| Environment | - |
| Working Temperature | -15 ~ 50°C |
| Storage Temperature | -40 ~ 85°C |
| Ambient Humidity | 5 ~ 90% (Non-condensing) |
