| Installation Type | Outdoor Wall-Mounted |
| Application | CCTV, Fiber Optic Distribution, Industrial Media Converters, Ethernet Switches |
| Panel Material | Electro-Galvanized Steel, Aluminum, or Stainless Steel |
| Panel Thickness | 2.0 mm |
| Bracket Material | Electro-Galvanized Steel, Aluminum, or Stainless Steel |
| Bracket Thickness | 2.0 mm |
| Dimensions (H × W × D) | 80.0 × 64.0 × 28.4 cm |
| Ground Wire | Green-Yellow, 2.5 mm² |
| Surface Finish | Electrostatic Powder Coating |
| Cabinet Color | Dark Gray |
| Door Lock | Push-Handle Lock with Flush Caps |
| Ventilation | Ventilation Fins on Both Sides |
| Pole-Mount Support | 2.0 mm Rear Support Bracket |
| Cooling Support | Supports up to 4 Blower Fans |
| Built-in Fans | 3 Fans with Filters |
| Water & Sun Protection | Rubber Gaskets and Sunshields |
| Internal Mounting Plate | Removable, 1.5 mm Thick |
| DIN Rail Support | Supported |
| Rain Protection | Integrated Rainproof Roof |
