| Heading | Value |
| Cabinet Material | Electro Galvanized |
| Cabinet Thickness | 1.2 mm |
| Dimension (H x W x D) | 740 x 500 x 250 mm |
| Ground Wire | Green/Yellow, 2.5 mm² |
| Cable Gland | 4 Cable Glands |
| Surface Finish | Electrostatic Powder Coating |
| Coating Standard | ASTM Standard |
| Cabinet Color | Dark Gray |
| Front Door Lock | Push Handle Lock |
| Ventilation | Ventilation Fins on Both Sides |
| Rear Support Plate | 2.0 mm Steel |
| Cooling System | Supports 4" Blower / Fan Installation |
| Water Protection | CNC Foam Gasket Sealing |
| Internal Mounting Plate | Removable 1.5 mm Plate |
| DIN Rail Support | Supported |
| Cable Entry Holes | 3/4" and 1" |
| Cable Management | Internal Cable Wire Guide |
| Fiber Capacity | Up to 24 Cores |
| Adapter Plate | 2 Plates |
| Grounding | Ground Connection Between Cabinet and Door/Lid |
| Internal Accessories Support | Splice Tray, Cable Management, Surge Protection and Breaker |
| Rain Protection | Protective Roof |
