| Product Specifications |
| Model |
NBS-2301P13 |
NBS-2301P26 |
NBS-2301P36 |
NBS-2301P55 |
NBS-2301P70 |
| Power Supply |
AC 100V-240V 50/60Hz |
| Power Consumption |
≤170W |
≤320W |
≤420W |
≤650W |
≤800W |
| Rated Power Output |
130W |
260W |
360W |
550W |
700W |
| Network Protocol |
TCP/IP, UDP, ARP, ICMP, IGMP |
| Audio Codec |
MP3, PCM/L16, ADPCM |
| S/N (Signal-to-Noise) Ratio |
Mic Input 1: ≥65dB; Mic Input 2/3: ≥80dB; Line Input 1/2: ≥82dB |
| THD (Total Harmonic Distortion) |
≤0.5% at 1kHz, 1/2 rated output |
| Frequency Response |
Mic Input 1: 80Hz-14kHz; Mic Input 2/3: 60Hz-16kHz; Line Input 1/2: 60Hz-16kHz |
| Speaker Output |
100V (Constant-Voltage) / 8-16Ω (Low-Impedance) |
| Interface |
1×RJ45 Ethernet Port, 1×SD Card Slot, 3×Mic Input (1/4” TS Jack), 2×Line Input (RCA Jack), 1×Line Output (RCA Jack), 3×Relay Input, 2×Relay Output, 1×4-Zone Speaker Output (100V), 1×4-Zone Speaker Output (100V), 2×Speaker Output (8-16Ω), 1×Speaker Output (100V), 1×Power Input |
| Dimensions |
483×430×88mm |
| Weight |
7.5kg |
| Standard Accessories |
2×6-Pin Terminal Block Connector, 1×Remote Control, 1×Protective Cover, 1×Installation Manual |
| Optional Accessories |
IEC C13 Power Cord (US/EU/UK/AU) |
