EPON ONU POE , 24 x 10/100M RJ45 ports

FEATURE
– Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
– Support auto discovery and auto register (real-time operation)
– Support DBA and multi types SLA; Support IEEE802.1D RSTP
– Support IGMP Snooping V2 multi-broadcast function
– Support EMI and ESD identification Support VLAN
– Support user end auto time synchronization based at SNTP
– Support powerful OAM and remote management
– Support port speed limit, loop detection and port VLAN
– Support state detection and fault location; Support power failure alarm
ㆍEach PoE port supports to auto discovery the standard power receiving devices

OVERVIEW
FO-7224P ONU is POE product, with twenty-four fixed 10/100Mbps auto-adapted POE ports. It supports IEEE802.3af
15.4W and IEEE802.3at 30W POE standards. It can auto discovery the power receiving devices which support IEEE802.3af/at
standard and supply power to it.
To the connected devices which not support PoE, it will auto stop supplying power. FO-7224P supports to work with
IP camera, IP phone, wireless AP and other network devices, and supply power to these devices. It works with central device OLT
to implement integrated management, long-distance fault location and decrease maintenance workload. It is metal casing design
and suitable for FTTB/FTTH.
