| Dimensions | 280mm (L) × 185mm (W) × 44mm (H) |
| Weight | About 1.62kg |
| User Port (LAN) | RJ-45 connector |
| LAN Ports | 8 × 10/100/1000Mbps adaptive network ports |
| Duplex Mode | Full/Half duplex |
| MDI/MDI-X | Auto MDI/MDI-X |
| Indicators | PWR / PON / SYS / LOS / LAN / POE / POE+LAN |
| PON Standard | EPON: 1000BASE-PX20+ symmetric / GPON: Class B+/Class C+ |
| PON Rate | EPON: 1.25Gbps downstream/upstream / GPON: 2.488Gbps downstream, 1.244Gbps upstream |
| Wavelength | Transmit: 1310nm / Receive: 1490nm |
| Receiving Sensitivity | EPON: -27dBm / GPON: -28dBm |
| Saturated Power | EPON: -3dBm / GPON: -8dBm |
| Transmitting Power | EPON: 0–4dBm / GPON: 0.5–5dBm |
| PoE Standard | Support PoE / PoE+ (PSE) |
| PSE Output Voltage | 48V DC |
| PoE Output Power | 120W |
| Single Port Maximum Output Power | 30W |
| Maximum Machine Power Consumption | 155W |
| Working Temperature | -10 to 50°C |
| Ambient Humidity | 10%–90% (Non-condensing) |
