| Heading | Value |
| Product Type | Single Output Power Supply for Battery Charge (UPS) |
| DC Output Voltage | CH1: 13.8V / CH2: 13.4V |
| Voltage Tolerance | ±2% |
| Rated Output Current | 2.0A |
| Output Current Range | 0–2.0A |
| Rated Power | 34.3W |
| Ripple & Noise | 120 mVp-p |
| DC Voltage Adjustment Range | CH1: 11.3–14.9V |
| Input Voltage Range | 90–264VAC / 127–370VDC |
| Input Current | 0.9A at 115VAC / 0.45A at 230VAC |
| Efficiency | 81% |
| Inrush Current | 25A at 115VAC / 45A at 230VAC |
| Leakage Current | < 1mA at 240VAC |
| Overload Protection | 110–150%, Hiccup Mode with Auto Recovery |
| Battery Low-Voltage Protection | 9.5–11V |
| Operating Temperature | -10°C to +60°C |
| Operating Humidity | 20–90% RH, Non-Condensing |
| Storage Temperature | -20°C to +85°C |
| Storage Humidity | 10–95% RH, Non-Condensing |
| Dimensions | 111 × 78 × 36 mm |
| Weight | Approx. 0.3 kg |
| Safety Standard | UL60950-1 / EN60950-1 |
| Warranty | 2 Years |
