| Chassis | Slim black metal chassis |
| Dimensions | 190 × 165 × 43 mm (L × W × H), 1.35-litre |
| Weight | 1.3 kg net |
| Mounting | VESA 75 × 75 mm / 100 × 100 mm included |
| Operating System | Windows 10 / Windows 11 64-bit / Linux 64-bit |
| Processor | Intel® Pentium® Gold 7505 |
| CPU Cores / Threads | 2 cores / 4 threads |
| CPU Clock | 2.0 GHz base / Up to 3.5 GHz |
| Smart Cache | 4 MB |
| Processor TDP | 15 W |
| Integrated Graphics | Intel® UHD Graphics |
| GPU | 48 Execution Units |
| Display Support | Up to 4 independent displays |
| Display Outputs | 4 × HDMI 2.0b |
| Maximum Resolution | 4096 × 2304 @ 60 Hz |
| Memory | 2 × DDR4-3200 SO-DIMM |
| Maximum Memory | 64 GB |
| 2.5" Storage | 1 × 2.5" SATA III HDD/SSD bay |
| M.2 Storage | 1 × M.2-2280 SSD slot |
| M.2 Storage Interface | PCIe Gen4 ×4 NVMe / SATA III |
| LAN | 2 × Gigabit Ethernet RJ45 |
| Ethernet Controller | 2 × Intel® i211 |
| WLAN Expansion | 1 × M.2-2230E slot |
| Card Reader | SD / SDHC / SDXC |
| Front USB | 4 × USB 3.2 Gen 2 Type-A |
| Rear USB | 4 × USB 3.2 Gen 1 Type-A |
| Serial Ports | 2 × RS232, one switchable to RS422 / RS485 |
| Audio | Realtek® ALC662 / ALC888S HD Audio |
| TPM | Firmware TPM 2.0 |
| Cooling | 50 mm temperature-controlled fan |
| Remote Power-On | Supported |
| Power Adapter | External 90 W fanless adapter |
| DC Input | 19 V DC |
| Operating Temperature | 0–50°C |
| Relative Humidity | 10–90% (Non-condensing) |
