| รายการ | รายละเอียด |
| Optional Cellular Network | • Network and Frequency Band:• FDD-LTE / TDD-LTE: 800/850/900/1700/1800/1900/21002300//2600• HSDPA 2100/1900/900/850Mhz• EDGE/GPRS/GSM 850/900/1800/1900Mhz |
| Transmission | • LTE: Class3 (23dBm±2dB)• WCDMA: Class 3 24dBm+1/3dB• GPRS/EDGE: Class E2 (27dBm±3dB)• Sensitivity: LTE B1/3: -101.5dBm, LTE B2/4/5/: -101dBm, LTE B7: -99.5dBm, WCDMA B 1/2/4: -110dBm, WCDMA B5: -110.5dBm |
| Power | • Voltage: DC 5 ~ 26V (standard 12V/1A power adapter)• Consumption Transfer mode: 70mA/12V (Average) Idle mode: 15mA/12V (Max) |
| Interface | • Antenna: SMA-K(Female), 50Ω• SIM Slot: Standard SIM/R-UIM interface, 3V• Serial data interface: Single Port type: RS-232/RS-485/RS-422/TTL, DB9 connector• Rate: 300-115200bps |
| Physical | • Housing: Metal• Dimension: 70.5mm x 55.5mm x 22mm (not including antenna)• Installation: Wall Mount or Desktop• Unit Weight: 150g (not including accessories) |
| Environment | • Operation temperature: -30 ~ +75 degree• Store temperature: -40 ~ +85 degree• Relative Humidity: < 95% (non-condensing)• Radiation: Anti-electromagnetic interference test @ 3 grade |
| Approval | • CE• RoHS• CCC |
| Standard | EN 301 489-1, 7, 24EN 301 511EN 301 908-1, 2, 13EN 55022EN 55024EN 60950-1EN 61000-3-2EN 61000-3-3EN 62311 |
