| รายการ | รายละเอียด |
| Optional Cellular Network | • Network and Frequency Band: FDD-LTE / TDD-LTE: 800/850/900/1700/1800/1900/2100/2300//2600MHz• HSDPA 2100/1900/900/850Mhz• EDGE/GPRS/GSM 850/900/1800/1900Mhz |
| Transmission | • LTE: Class3 (23dBm±2dB)• WCDMA: Class 3 (24dBm+1/3dB)• GPRS/EDGE: Class E2 (27dBm±3dB)• Sensitivity: LTE B1/3: -101.5dBm, LTE B2/4/5/: -101dBm, LTE B7: -99.5dBm, WCDMA B 1/2/4: -110dBm, WCDMA B5: -110.5dBm |
| Power | • Voltage: DC 7.5 ~ 26V (standard 12V/1A power adapter)• SIM/R-UIM Card: 3V• Consumption: Transfer mode: 80mA/12v (Average) Idle mode: 7mA/12v (Max) |
| Interface | • Antenna: SMA-K(Female), 50Ω• SIM Slot: Standard SIM/R-UIM interface• Serial data interface: 1xRS-232, 1xRS-485, Terminal block connector• Rate: 300-115200bps |
| Physical | • Housing: Metal• Dimension: 72.2mm x 64mm x 25.5mm (not including antenna)• Installation: Wall Mount or Desktop• Unit Weight: 150g (not including accessories) |
| Environment | • Operation temperature: -30 ~ +75 degree• Store temperature: -40 ~ +85 degree• Related humidity: <95% (non-condensing)• Radiation: Anti-electromagnetic interference test @ 3 grade |
| Approval | • CE• RoHS• CCC |
| Standard | EN 301 489-1, 7, 24EN 301 511EN 301 908-1, 2, 13EN 55022EN 55024EN 60950-1EN 61000-3-2EN 61000-3-3EN 62311 |
