| รายการ | รายละเอียด |
| Optional Mobile Network | • FDD / TDD 4G • DC-HSPA+/HSPA+/HSPA/WCDMA/UMTS 3G • EDGE/GPRS 2.5G • CDMA2000 EVDO/CDMA 1X |
| Ethernet Standard | • IEEE 802.3 • IEEE 802.3u |
| Interface | • 2x10/100Mb LAN interface • 1x LAN, 1xWAN (optional) • 1x RS-232 console port (optional) • 2x SMA-K antenna interface • 1x Standard SIM/R-UIM interface • 1x Standard DC power interface |
| LED instruction | • Net • WLAN • WAN • LAN |
| Route protocol | • Static route • RIPv2/OSPF dynamic route |
| Power supply | • 5 - 32VDC |
| Device management | • Local or remote web browser (IE v8 or above) • CLI/Telnet command • M2M management platform (optional) • SSH configure (optional) |
| WiFi | • Standard: IEEE 802.11b/g/n • WEP, WPA and WPA2 encryption • Standard 150Mbps, 300Mbps optional • AP, Client, station, bridge mode support |
| Firewall & Filter | • IP packet/Domain/MAC filter • NAT • DMZ |
| VPN | • IPSec • PPTP/L2TP client • GRE/IPIP |
| Power Consumption | • Idle: 165mA@+12VDC • Online (Without WiFi): 195mA@+12VDC • With WiFi: 235mA@+12VDC |
| Other | • Dimension: 103mm x 73.5mm x 25.5mm (not including antenna) • Weight: 300g • Operation temperature: -30~+70°C • Store temperature: -40~+85°C • Related humidity: <95% (non-condensing) • Guarantee: one year |
| Standard | • EN 300 328 v1.7.1 (2016-11) • EN 301 489-1 • EN 301 908-1 • EN 55022:2010/AC:2011 • EN 55024:2010 • EN 61000-3-3:2008 • EN 301 489-17 • EN 301 511 • EN 301 908-13 • EN 60950-1 • EN 61000-3-2 • EN 62311:2008 |
| Approval | • CE • RoHS • CCC |
